MSO5000HD-MANCH

MSO5000HD-MANCH – Manchester Protocol Decode Option

📡 Decode Clock-Embedded Data Streams with the MSO5000HD

The UNI-T MSO5000HD Series oscilloscope is engineered for precision signal analysis in complex embedded and communication systems. With its 12-bit resolution and up to 1 GHz analog bandwidth, it’s the ideal platform for decoding encoded serial transmissions. The MSO5000HD-MANCH option unlocks decoding and triggering support for Manchester-encoded signals, which embed clock and data into a single self-synchronizing stream.

Manchester encoding is commonly used in RFID, IR communication, Ethernet (10BASE-T), magnetic stripe readers, and legacy bus systems. This decode license helps engineers easily visualize logic-level transitions, detect synchronization issues, and interpret data that would otherwise require a manual decode process.

🔍 Key Capabilities

• Decode standard Manchester-encoded bitstreams in real time

• Display bit-level and frame-level interpretation on waveform overlays

• Trigger on sync patterns, user-defined bit sequences, or errors

• Event table for browsing decoded bits and timing

• Support for both IEEE and G.E. Manchester polarity formats

• Capture and correlate analog anomalies like jitter, overshoot, or reflections

🧠 Benefits of MSO5000HD-MANCH

• Visualize Data and Timing in One View
  Decode clock-embedded waveforms and instantly correlate logic transitions with signal integrity issues.

• Faster Debugging of Legacy and Specialty Buses
  No more converting waveforms to logic manually—everything is decoded and searchable in real time.

• Polarity-Aware Triggering
  Supports different Manchester conventions and lets you focus on the pattern that matters.

🛠️ Ideal Applications

• Industrial and automotive legacy communication systems

• RFID and magnetic card reader development

• 10BASE-T Ethernet (legacy debugging or training)

• Infrared data systems (IrDA)

• Clock-data recovery in custom serial formats

🔗 Bundle Availability

The MSO5000HD-MANCH decode option is also included in:

• ✅ MSO5000HD-BND – the complete protocol bundle for MSO5000HD series

View the bundle:

• MSO5000HD-BND product page →

🧩 Optional Unlockable Software Features – MSO5000HD Series

🔌 Protocol Decode Options

These licenses unlock triggering and decoding for specific digital protocols:

• MSO5000HD-CANFD – CAN FD (Flexible Data Rate)

• MSO5000HD-CANXL – CAN XL (next-generation automotive network)

• MSO5000HD-FLEX – FlexRay (time-deterministic automotive bus)

• MSO5000HD-SENT – SENT (Single Edge Nibble Transmission, used for sensors)

• MSO5000HD-AUDIO – I2S, Left Justified (LJ), Right Justified (RJ), and TDM audio protocols

• MSO5000HD-ARINC429 – ARINC 429 (aerospace serial bus)

• MSO5000HD-MIL1553 – MIL-STD-1553B (military avionics bus)

• MSO5000HD-MANCH – Manchester encoding protocol

• MSO5000HD-1WIRE – 1-WIRE protocol

• MSO5000HD-I3C – I3C (improved two-wire interface for embedded systems)

⚠️ RS232, UART, SPI, I2C, CAN, and LIN are included as standard and require no license.

📈 Power Analysis

MSO5000HD-PWR – Unlocks the oscilloscope’s integrated power analysis features for evaluating:

• Power quality

• Harmonic distortion

• Rds(on), switching loss

• Safe operating area

• Slew rate, ripple, transient response, and efficiency

🎛️ Function Generator & Bode Plot

MSO5000HD-AWG – Enables the dual-channel 50 MHz arbitrary waveform generator

• Used for signal injection, loop testing, and frequency response analysis

• Required for full use of the Bode Plot mode

⏱️ Timing Analysis

MSO5000HD-TIME – Unlocks the Time Sequence Analyzer

• Measures setup/hold time, edge detection, amplitude, and pulse width

• Supports test report export for buses such as I2C, SPI, CAN, and I2S

📶 Bandwidth Upgrade

Bandwidth unlocks are available to upgrade lower-tier models to higher bandwidth tiers:

• Example: Upgrade 350 MHz model to 500 MHz or 1 GHz
