MSO5000HD-MIL1553

MSO5000HD-MIL1553 – MIL-STD-1553B Protocol Decode Option

✈️ Military-Grade Bus Analysis on the MSO5000HD

The UNI-T MSO5000HD Series delivers uncompromising visibility into complex avionics and defense-grade embedded systems. With high-resolution 12-bit analog capture, deep 500 Mpts memory, and up to 1 GHz bandwidth, it’s the perfect platform for decoding time-critical and noise-sensitive serial buses. The MSO5000HD-MIL1553 unlocks full decode and trigger support for MIL-STD-1553B, the fault-tolerant, dual-redundant serial protocol used in aerospace, defense, and military ground vehicles.

Designed for mission-critical applications, MIL-STD-1553B uses a command/response structure, Manchester encoding, and strict timing constraints—all of which demand a deep and specialized view that this software option provides.

🔍 Key Capabilities

• Decode full MIL-STD-1553B transactions: command words, status words, and data words

• Trigger on specific RT addresses, subaddresses, mode codes, or error types

• View Manchester-encoded signal transitions and bit-level overlays

• Use the event table to navigate transactions with timestamps and protocol fields

• Detect common faults: parity errors, sync issues, invalid responses, or command timing violations

🧠 Benefits of MSO5000HD-MIL1553

• Precision Avionics Debugging
  Decode and validate bus communication between flight control systems, weapons management, and telemetry modules.

• Time-Correlated Signal Integrity
  Identify jitter, reflections, or power supply fluctuations that could corrupt otherwise-valid messages.

• Standard-Compliant Testing
  Visualize bus arbitration, RT-to-RT transfers, and message scheduling with full decode detail.

🛠️ Ideal Applications

• Military avionics development and integration

• Flight control system diagnostics

• Naval or armored vehicle electronics validation

• Satellite and launch vehicle communication systems

• Defense training labs and protocol education

🔗 Bundle Availability

The MSO5000HD-MIL1553 decode option is also included in:

• ✅ MSO5000HD-BND – full protocol unlock for every decode option available on the MSO5000HD platform

Explore the bundle:

• MSO5000HD-BND product page →

🧩 Optional Unlockable Software Features – MSO5000HD Series

🔌 Protocol Decode Options

These licenses unlock triggering and decoding for specific digital protocols:

• MSO5000HD-CANFD – CAN FD (Flexible Data Rate)

• MSO5000HD-CANXL – CAN XL (next-generation automotive network)

• MSO5000HD-FLEX – FlexRay (time-deterministic automotive bus)

• MSO5000HD-SENT – SENT (Single Edge Nibble Transmission, used for sensors)

• MSO5000HD-AUDIO – I2S, Left Justified (LJ), Right Justified (RJ), and TDM audio protocols

• MSO5000HD-ARINC429 – ARINC 429 (aerospace serial bus)

• MSO5000HD-MIL1553 – MIL-STD-1553B (military avionics bus)

• MSO5000HD-MANCH – Manchester encoding protocol

• MSO5000HD-1WIRE – 1-WIRE protocol

• MSO5000HD-I3C – I3C (improved two-wire interface for embedded systems)

⚠️ RS232, UART, SPI, I2C, CAN, and LIN are included as standard and require no license.

📈 Power Analysis

MSO5000HD-PWR – Unlocks the oscilloscope’s integrated power analysis features for evaluating:

• Power quality

• Harmonic distortion

• Rds(on), switching loss

• Safe operating area

• Slew rate, ripple, transient response, and efficiency

🎛️ Function Generator & Bode Plot

MSO5000HD-AWG – Enables the dual-channel 50 MHz arbitrary waveform generator

• Used for signal injection, loop testing, and frequency response analysis

• Required for full use of the Bode Plot mode

⏱️ Timing Analysis

MSO5000HD-TIME – Unlocks the Time Sequence Analyzer

• Measures setup/hold time, edge detection, amplitude, and pulse width

• Supports test report export for buses such as I2C, SPI, CAN, and I2S

📶 Bandwidth Upgrade

Bandwidth unlocks are available to upgrade lower-tier models to higher bandwidth tiers:

• Example: Upgrade 350 MHz model to 500 MHz or 1 GHz
