MSO3000X-FLEX

MSO3000X-FLEX – FlexRay Protocol Decode Option

🛡️ High-Speed, Time-Deterministic Bus Decoding for Safety-Critical Systems

The MSO3000X-FLEX unlock enables triggering, decoding, and frame analysis of the FlexRay protocol—a high-speed, deterministic bus used in advanced automotive systems including drive-by-wire, brake-by-wire, and ADAS modules. By adding this option to your UNI-T MSO3000X Series oscilloscope, you’ll gain time-aligned visibility into FlexRay’s static and dynamic segments, complete with message ID decoding, cycle timing, and error detection.

This unlock is a must for developers working on time-sensitive vehicle networks where reliability and redundancy are critical.

✅ Always-Included Standard Protocols

Your MSO3000X scope already supports:

• RS-232 / UART

• I²C

• SPI

🧩 FlexRay decoding requires the MSO3000X-FLEX unlock.

🔓 What You Unlock with MSO3000X-FLEX

🧠 Real-World Use Cases

✅ ADAS Subsystem Debugging

Decode communication between radar, camera, and sensor fusion ECUs using FlexRay for synchronized decision making.

✅ Vehicle Dynamics Module Testing

Analyze FlexRay-based communication between brake-by-wire, steering control, and suspension modules.

✅ Zonal Network Architecture Validation

Time-align FlexRay messages with CAN, SENT, or LIN events to validate gateway behavior and priority handling.

✅ Redundancy and Error Testing

Simulate or capture bus faults and confirm system fallbacks or re-transmission logic under stress conditions.

🔧 Technical Features

• Decode full FlexRay frames: header, payload, and CRC

• Support for static/dynamic segment and cycle counter decode

• Real-time waveform overlay with ID, cycle, and payload

• Flexible triggering by ID, sync pattern, or error flag

• Compatible with differential signal probing

🛠️ Ideal For

• OEM and Tier 1 automotive ADAS teams

• Safety-critical ECU developers

• Vehicle network validation engineers

• Automotive labs and R&D facilities

• Educators teaching deterministic bus systems

🔗 Related Options

• ✅ MSO3000X-CAN-FD → – High-speed CAN bus decoding

• ✅ MSO3000X-LIN → – LIN protocol for automotive body electronics

• ✅ MSO3000X-SENT → – Single Edge Nibble Transmission for sensors

• ✅ MSO3000X-AUTO → – Automotive bundle (CAN, CAN-FD, LIN, FlexRay, SENT)

• ✅ MSO3000X-BND → – Full protocol decode suite

📋 MSO3000X Unlock Overview

Standard Features:
✔ RS-232 / UART
✔ I²C
✔ SPI

MSO3000X-FLEX Unlocks:
✔ FlexRay triggering, decoding, and logging for high-speed, fault-tolerant vehicle networks

Additional Unlockable Options:
CAN / CAN FD / LIN / SENT
AUDIO / MIL-STD-1553 / ARINC 429 / Manchester
PWR / AWG
AUTO & BND Bundles
