MSO3000X-BND Serial Bus Trigger and Decode Options Bundle (Includes AUTO, AUDIO, MIL-STD, ARINC429, MANCH)
Overview
The MSO3000X-BND unlocks the entire library of serial bus analysis options for your MSO3000X Series oscilloscope in a single license — automotive (CAN, CAN-FD, FlexRay, SENT, LIN), audio (Audio (I2S/LJ/RJ/TDM)), aerospace (MIL-STD-1553, ARINC 429), wireless/industrial (Manchester). One key, every protocol.
Purchasing the 9 included protocols individually totals $2,511. The BND bundle price of $1,129 saves you $1,382 — a 55% discount. Future-proof your bench and eliminate procurement delays.
Key Features
-
What's Included — 9 protocols with full trigger, decode, and search:
- CAN (Controller Area Network) — $279 individually
- CAN-FD — $279 individually
- FlexRay — $279 individually
- SENT (SAE J2716) — $279 individually
- LIN (Local Interconnect Network) — $279 individually
- Audio Serial Bus (I2S, LJ, RJ, TDM) — $279 individually
- MIL-STD-1553 — $279 individually
- ARINC 429 — $279 individually
- Manchester Encoding — $279 individually
- Save $1,382 (55% Off) — Bundle pricing vs. purchasing individually.
- Single License Key — One key unlocks all protocols. No managing separate licenses.
- Future-Proof — Every protocol ready when you need it. No procurement delays.
- Software License Activation — Applied via license key. No hardware changes.
When You Need This
Multi-Domain Development
Your product uses multiple bus types. The BND covers everything from day one — saving $1,382 vs. individual purchases.
Test Lab Ready for Anything
Serves clients across automotive, aerospace, and consumer electronics. Every protocol available without scrambling for licenses mid-project.
Compatible Instruments
This option is compatible with all MSO3000X Series oscilloscopes: MSO3034X (350 MHz) and MSO3054X (500 MHz).
Own a Different Instrument?
Need protocol bundle on a different oscilloscope? These series also offer it: MSO/UPO2000, MSO/UPO3000CS, MSO2000X, MSO3000HD, MSO5000HD, MSO7000X, MSO8000HD, UPO7000L.
Explore Other MSO3000X Options
Frequently Asked Questions
I only need two protocols. Is the bundle worth it?
Compare the combined individual prices to the bundle at $1,129. At 55% off, the bundle often wins at just two or three protocols — and future projects may need more.
Does BND include power analysis, AWG, or bandwidth upgrades?
No. BND covers serial bus protocols only. MSO3000X-AWG Arbitrary Waveform Generator option, MSO3000X-PWR Power Analysis Option are separate options.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
