In the continuously evolving field of electronics and telecommunications, the need for precision and versatility remains constant. Introducing the UNI-T UTS5026A 26.5GHz Performance-Series Signal Analyzer–a robust instrument meticulously crafted to fulfill the demanding requirements of electrical engineers, RF professionals, and educators specializing in electrical and RF engineering. Covering an extensive frequency range from 9kHz to an impressive 26.5GHz, this advanced analyzer unlocks a plethora of advantages and applications.

For electrical and RF engineers venturing into cutting-edge projects that demand high-frequency analysis, such as satellite communication systems, microwave technology, and radar systems, the UTS5026A proves indispensable. Its extended frequency range equips professionals to navigate the intricacies of these high-frequency applications, guaranteeing precision and accuracy in their endeavors.

The UNI-T UTS5026A delivers outstanding selectivity, ensuring unparalleled signal resolution even when faced with adjacent unequal amplitudes. This capability is crucial in situations where precise signal separation and analysis are essential, such as identifying interference sources in densely populated frequency bands.

Challenges arise when testing weaker signals due to the spectrum analyzer's inherent noise floor. The UTS5026A series, with an impressive Displayed Average Noise Level (DANL) as low as -163dBm, excels in sensitivity. This feature proves essential for effectively testing weak signals, particularly in applications where signal strength is minimal, such as monitoring low-power transmissions or detecting subtle signal variations.

The UNI-T UTS5026A signal analyzer, with a Resolution Bandwidth (RBW) range from 1Hz to 3MHz in 10% steps, and options for 4, 5, 6, and 8MHz, provides RF engineers with unparalleled flexibility in signal analysis. The 1Hz minimum RBW allows for precise separation of closely spaced signals, critical for applications like spectrum monitoring, interference detection, and signal demodulation. This fine control over bandwidth ensures detailed signal resolution, helping engineers accurately identify and analyze even the faintest signals, making it ideal for tasks in crowded RF environments where precision is paramount.

A 15.6-inch multi-touch HD capacitive screen facilitates swift menu adjustments, supporting various gestures like dragging, expanding, and zooming out on the trace. This user-friendly interface streamlines human-computer interaction, addressing the challenge of cumbersome and complex operations.

The UTS5026A offers both internal and external reference source options, automatically switching to an external reference source when a 10MHz clock signal is detected. This flexibility streamlines synchronization with other devices, critical in applications demanding precise synchronization, such as network timing.

The UNI-T UTS5026A signal analyzer, with 100,001 scan points, offers RF engineers precise and detailed frequency analysis. Its high resolution enables accurate detection of even minor signal variations, making it ideal for identifying interference, optimizing systems, and ensuring regulatory compliance. With enhanced troubleshooting and performance tuning, this analyzer boosts system reliability and efficiency, helping engineers achieve superior results in less time.

The UNI-T UTS5026A signal analyzer, with phase noise as low as -107 dBc/Hz (1 GHz, 10 kHz offset), delivers exceptional clarity and precision, crucial for RF engineers working on sensitive applications. Low phase noise minimizes interference in frequency measurements, ensuring cleaner signals and more accurate readings, particularly in high-performance systems like satellite communications and radar.

The UNI-T UTS5026A signal analyzer allows RF engineers to conduct EMI pre-compliance testing up to 26.5GHz, ensuring early detection of interference issues. This reduces the risk of costly redesigns and accelerates development by addressing potential EMI problems before formal testing. Ideal for telecommunications, aerospace, and defense, the UTS5026A helps engineers meet strict regulatory standards with ease and confidence.

Equipped with a removable dust filter, users can clean the air inlet to remove accumulated dust after prolonged use. This maintenance feature is essential for ensuring the overall reliability of the instrument, preventing potential issues such as short-circuits, burns, or fires caused by dust accumulation.

Offering a hands-on experience with cutting-edge equipment, educators successfully bridge the divide between theoretical knowledge and practical application, effectively preparing students for real-world challenges in the field. Within the domain of education, the UTS5026A stands out as an exemplary instructional tool. It empowers educators specializing in electrical and RF engineering to acquaint students with the intricacies of handling high-frequency RF signals.

The UNI-T UTS5026A 26.5GHz Performance-Series Spectrum Analyzer serves as a flexible solution for electrical engineers, RF professionals, and educators. Whether your focus is on signal analysis, EMI compliance, or advanced measurements, this instrument provides the tools to excel in your specific field. Uncover new opportunities in electrical and RF engineering by acquiring the UTS5026A today!

Warranty & Support

All UNI-T UTS5000A Series signal analyzers include a 3-year warranty covering parts and labor under normal use. Standard accessories (including probes and cables) are covered by a 1-year warranty. Register your UTS5000A for a free, 2-year warranty extension.
