UPO7000L-PWR

UPO7000L-PWR – Advanced Power Analysis Unlock

⚡ Make Better Power Designs Faster with Integrated Power Measurement Tools

The UPO7000L-PWR software unlock transforms your UNI-T UPO7000L Series oscilloscope into a fully equipped power analysis workstation. Designed for power electronics engineers, system integrators, and embedded developers, this option adds a complete suite of automated measurements to evaluate switching behavior, power quality, efficiency, and dynamic performance.

From ripple and switching loss to Bode plots and harmonic distortion, this feature set helps you uncover real-world inefficiencies and instability in your designs—without the need for external analyzers or manual math setups.

🔍 Power Measurement Capabilities & Real-World Applications

🧠 Examples That Highlight the Value

✅ Switching Regulator Optimization

You’re designing a synchronous buck converter and want to compare different MOSFETs. With the Switching Loss tool, measure exactly how much energy is lost during turn-on and turn-off events at full load. Make data-driven decisions—not estimates.

✅ Power Integrity for High-Speed Logic

Ripple analysis lets you visualize millivolt-level disturbances on 1.0 V or 1.2 V rails. Validate if those voltage dips are responsible for logic resets, communication errors, or system instability.

✅ Boost Converter Stability Check

Use the AWG (UPO7000L-AWG required) to inject a frequency sweep into your compensation network. The loop gain/Bode plot feature shows if your design has enough phase margin to survive startup, transients, and worst-case conditions.

✅ AC Inverter Harmonics

Perform harmonic analysis on an inverter's output waveform. Identify and mitigate 3rd, 5th, or 7th harmonics that may lead to transformer heating, noise, or failed compliance.

🔧 Features & Capabilities

• Automated switching loss integration with adjustable turn-on/off detection

• SOA diagrams with real-time device stress boundaries

• Ripple and noise overlays with high-resolution vertical scaling

• True efficiency calculation with math-based input/output power capture

• Bode plot mode with frequency sweep up to 20 MHz

• Harmonic spectrum analysis on voltage or current waveforms

• Pass/fail margin testing and PDF report generation

🛠️ Ideal Applications

• DC-DC converter development and benchmarking

• Motor drive and inverter system validation

• High-efficiency LED driver analysis

• Battery-powered embedded design optimization

• EMI root cause analysis and pre-compliance checks

• University and training labs teaching real-world power electronics

🔗 Related Unlock Options

• ✅ UPO7000L-AWG → – Required for Bode plot and frequency response testing

• ✅ UPO7000L-JIT → – Analyze jitter and eye diagrams in power control signals

• ✅ UPO7000L-BND → – Full unlock bundle including power, jitter, and all protocol decodes

📋 Optional Unlocks for UPO7000L Series

Standard decode protocols included: RS-232/UART, I²C, SPI, CAN, LIN
Optional upgrades:

• UPO7000L-PWR – This page

• UPO7000L-JIT – Jitter and Eye Analysis

• UPO7000L-AWG – Arbitrary waveform generator (1 channel)

• UPO7000L-CANFD – CAN FD decode

• UPO7000L-FLEX – FlexRay decode

• UPO7000L-SENT – SENT decode

• UPO7000L-AUDIO – I2S, LJ, RJ, and TDM decode

• UPO7000L-AREO – MIL-STD-1553 and ARINC 429 aerospace bundle

• UPO7000L-BND – Complete bundle with all available unlocks
