UPO7000L-BW-10T20

UPO7000L-BW-10T20 – Bandwidth Upgrade: 1.0 GHz → 2.0 GHz

📶 Double Your Bandwidth. Expand Your Debug Power.

Already using a 1 GHz UNI-T UPO7000L Series oscilloscope? The UPO7000L-BW-10T20 unlockable upgrade boosts your analog bandwidth to a full 2 GHz, allowing you to capture ultra-fast edges, resolve GHz-class harmonics, and analyze RF behavior with superior fidelity.

This is a software-based upgrade—no hardware change, no calibration downtime. Just more bandwidth, more clarity, and more engineering insight.

🔧 What You Gain with 2 GHz Bandwidth

• Capture signal edges and fast pulses below 200 ps rise time

• Analyze fast transitions in GaN/SiC power devices

• Resolve overshoot, ringing, and crosstalk with higher precision

• Improve time-correlation of RF, analog, and digital channels

🧠 Why Engineers Choose UPO7000L-BW-10T20

✅ RF and Analog Front-End Debugging

Resolve modulation shapes, switching spikes, and RF burst edges without needing a spectrum analyzer.

✅ High-Speed Digital Validation

Ensure signal integrity on interfaces like PCIe, USB 3.x, MIPI, or DDR memory with sub-nanosecond edge resolution.

✅ Pulse and Transient Capture

Accurately characterize steep waveform edges, RF pulses, or analog transitions that are lost at lower bandwidths.

✅ Future-Proof Your Investment

Stay ready for next-generation protocols and topologies with 2 GHz analog performance and high sampling rates.

🛠️ Compatibility

• Applies to UPO7000L Series models currently licensed at 1 GHz

• Software license unlock—no shipping, hardware swap, or downtime

• Permanent bandwidth upgrade after activation

🔗 Related Unlock Options

• ✅ UPO7000L-JIT → – Jitter and eye diagram analysis for fast edges

• ✅ UPO7000L-PWR → – Power switching loss and loop analysis

• ✅ UPO7000L-BND → – Complete bundle of decode and analysis tools

📋 UPO7000L Unlock Summary

Included standard protocols: RS-232/UART, I²C, SPI, CAN, LIN
Available upgrades:

• UPO7000L-BW-10T20 – This page

• UPO7000L-PWR – Power analysis

• UPO7000L-JIT – Jitter and eye diagram tools

• UPO7000L-AWG – Arbitrary waveform generator

• UPO7000L-CANFD – CAN FD decode

• UPO7000L-FLEX – FlexRay decode

• UPO7000L-SENT – SENT decode

• UPO7000L-AUDIO – I2S, LJ, RJ, TDM decode

• UPO7000L-AREO – MIL-STD-1553 + ARINC 429 decode

• UPO7000L-BND – Full unlock bundle
