MSO2000X-BW1MT2M

MSO2000X-BW1MT2M – Bandwidth Upgrade: 100 MHz → 200 MHz

📈 Double Your Measurement Bandwidth

The MSO2000X-BW1MT2M upgrade license unlocks a bandwidth increase from 100 MHz to 200 MHz on compatible UNI-T MSO2000X Series oscilloscopes. This upgrade enhances the scope’s ability to capture faster edge transitions, observe higher-frequency harmonics, and improve signal integrity analysis—all without changing hardware.

Perfect for users who outgrow their 100 MHz model or want extended measurement headroom for future projects.

🔓 What You Unlock with MSO2000X-BW1MT2M

✅ Doubles analog bandwidth
✅ No hardware modification required
✅ Keeps full sample rate and memory depth

🧠 Why Upgrade to 200 MHz?

• ✅ Faster Edge Visibility
  Capture cleaner rise/fall transitions in digital and analog signals.

• ✅ Extended Frequency Range
  Analyze RF, clock, and fast switching power signals up to ~100 MHz fundamental frequency.

• ✅ Better Accuracy for Harmonics
  Observe signal distortion and overshoot with greater clarity.

• ✅ Signal Debug Headroom
  Avoid aliasing when signals exceed your original 100 MHz limit.

🔧 Technical Highlights

• Works with MSO2104X model (100 MHz base bandwidth)

• Retains full 5 GSa/s sampling rate and 100 Mpts memory depth

• Applies to all 4 analog channels

• Unlock license installed via software key (no hardware swap)

🛠️ Ideal For

• Users who purchased 100 MHz models but now require higher signal fidelity

• Educators who want a single oscilloscope to handle broader lab exercises

• Engineers scaling from basic to intermediate debugging tasks

🔗 Related Bandwidth Upgrade Options

• MSO2000X-BW1MT3M – Upgrade 100 MHz → 300 MHz

• MSO2000X-BW2MT3M – Upgrade 200 MHz → 300 MHz

📋 MSO2000X Bandwidth Upgrade Summary

Upgrade From: MSO2104X (100 MHz)
Upgrade To: Equivalent 200 MHz model
Method: License key activation
Applies To: All analog channels
