UNI-T MSO2000X Options Series

MSO2000X-AUDIO – Digital Audio Protocol Decode Option

🎧 Decode I²S, LJ, RJ, and TDM Audio Interfaces

The MSO2000X-AUDIO license adds digital audio protocol decoding to your UNI-T MSO2000X Series oscilloscope. Supporting I²S (Inter-IC Sound), Left Justified (LJ), Right Justified (RJ), and TDM (Time-Division Multiplexing) formats, this option is ideal for analyzing audio data between DACs, codecs, DSPs, and embedded microcontrollers.

With this license enabled, the oscilloscope can trigger on audio word alignment, decode left/right channel data, and correlate timing and data integrity issues directly with physical-layer waveforms—making it a powerful debug tool for embedded audio system developers.

✅ Standard Serial Protocols Always Included

All MSO2000X Series models include built-in support for:

RS-232 / UART
I²C
SPI

🧩 Digital audio decoding is optional and requires the MSO2000X-AUDIO license.

🔓 What You Unlock with MSO2000X-AUDIO

Feature	Description & Use Case Example
Trigger on Frame or Word Select	Sync to word clock or left/right data select.📌 Verify channel timing and alignment.
Decode Left, Right, or All Channels	Extract and view audio payload in real time.📌 Monitor digital audio content frame-by-frame.
Format-Specific Support	I²S, LJ, RJ, and TDM protocols📌 Analyze various bus formats used in modern AV systems.
Error and Glitch Detection	Spot missing bits, sync loss, or framing issues.📌 Troubleshoot jitter and EMI-related faults.
Export Decoded Logs	Create time-stamped logs for waveform review or reports.📌 Ideal for test documentation.

🧠 Real-World Use Cases

✅ Codec and DAC Interface Testing
Validate timing and data from I²S or TDM digital audio buses.
✅ Audio Glitch Troubleshooting
Capture sync loss or corrupted channels during power cycling or load.
✅ Embedded Audio System Development
Correlate decoded audio data with processor outputs during firmware testing.
✅ Audio Bus Latency Measurement
Measure delays between command and playback or error recovery.

🔧 Technical Highlights

Supports I²S, Left Justified, Right Justified, and TDM formats
Trigger on Word Select, Left/Right Channel, Any Word, or Sync Error
Works with analog CH1–CH4 or digital D0–D15
View full decode overlays and protocol listings in real time
Export logs in CSV or PDF formats for analysis

🛠️ Ideal For

Audio hardware developers
Embedded system designers
Automotive infotainment engineers
AV equipment manufacturers
Educators in signal processing and embedded audio

🔗 Related Unlock Options

FlexRay Decode – For deterministic ADAS networks
CAN FD Decode – For high-speed vehicle communications
SENT Protocol – For digital automotive sensor buses
Full Protocol Suite – Includes AUDIO, CAN FD, SENT, LIN, and more
AWG Generator – Simulate digital or analog audio signals
Power Analysis – Examine ripple and noise on AV system supplies

📋 MSO2000X Unlock Summary

Always Included:

✔ RS-232 / UART
✔ I²C
✔ SPI

MSO2000X-AUDIO Adds:

✔ Real-time decode of I²S, LJ, RJ, and TDM buses
✔ Format-specific trigger and channel decoding
✔ Sync error and timing diagnostics
✔ Audio frame logging for review and reports
