100 MHz 2-channel mixed signal oscilloscope with 2 GSa/s sample rate, 56 Mpts memory depth. Nine-in-one instrument suited for production, field service, and multi-domain troubleshooting.

View full details

UPO2102 | 100 MHz 2Ch Oscilloscope (Logic Pod Optional)

Overview

The UPO2102 is a 100 MHz mixed signal oscilloscope with 2 analog channels. Digital channels available via optional UT-M15 logic probe pod. It samples at 2.0 GSa/s with 56 Mpts memory depth and captures waveforms at up to 1,000,000 wfms/s — one of the fastest capture rates in its class — on an 8-inch capacitive touchscreen.

The oscilloscope provides 36 automated measurements with statistics, advanced triggering (edge, pulse width, slope, video, pattern, and area trigger), FFT spectrum analysis, and web-based remote control via LAN. Serial bus protocol decoding for RS-232, UART, I²C, SPI, CAN, CAN-FD, LIN, and FlexRay is available as optional software licenses.

UPO2000E waveform capture — High-speed waveform capture with intensity grading

Key Features

100 MHz Bandwidth, 2 Analog Channels — Two-channel capture at up to 100 MHz.
2.0 GSa/s Sample Rate — Captures fast edges and high-frequency content with accurate timing.
56 Mpts Memory Depth — Extended capture without reducing sample rate.
1,000,000 wfms/s Capture Rate — Industry-leading acquisition speed reveals rare glitches, runts, and timing violations.
16 Digital Channels (Optional) — Add mixed-signal capability with the UT-M15 logic probe pod.
36 Automated Measurements — Time, voltage, frequency, and statistical measurements with real-time tracking.
Area Trigger — Draw a region on screen to trigger on waveform anomalies.
FFT Spectrum Analysis — Frequency domain analysis for harmonics, EMI, and spectral characterization.
8-Inch Capacitive Touchscreen — Pinch, zoom, and drag for efficient waveform navigation.
Web Remote Control — Browser-based access from any device on the LAN.
Connectivity — USB, LAN, VGA, EXT trigger, AUX output.

Deep Memory for Extended Capture

With 56 Mpts of memory, the oscilloscope maintains high sample rates across wide time base settings. Capture complete communication sequences, power-on cycles, or slow mechanical processes without aliasing. Zoom into any portion of the record at full resolution.

UPO2000E memory depth — 56 Mpts deep memory for extended signal capture

UPO2000E measurement functions — Comprehensive measurement and analysis functions

Comprehensive Measurement and Analysis

The oscilloscope provides 36 automated measurements covering time, voltage, frequency, and statistical parameters. Min/max/average/standard deviation tracking runs in real time. The built-in FFT provides frequency domain analysis for identifying harmonics, EMI, and spectral components.

Optional Mixed-Signal Capability

The UPO2000 platform supports 16 digital channels via the optional UT-M15 logic probe pod. Once connected, digital channels display alongside analog traces with full time correlation — the same mixed-signal capability as the MSO models, added when you need it.

UPO2000E display and interface — Clear display with intuitive front-panel controls

MSO2000 advanced trigger types — Advanced trigger types for isolating specific signal conditions

Advanced Triggering

Beyond standard edge triggering, the MSO/UPO2000 supports pulse width, slope, video, pattern, timeout, and area triggers. The area trigger lets you draw a region on screen and trigger when a waveform enters or exits it — effective for catching anomalies where you know the expected signal shape.

Professional Applications

Embedded Systems Development — Debug firmware with time-correlated analog and digital views. Decode SPI, I²C, UART, and CAN bus traffic alongside power rails and clock signals.
Power Electronics — Capture switching waveforms with deep memory, trigger on specific conditions, and use FFT to characterize switching noise and harmonics.
Education and Training — Touchscreen interface and automated measurements for teaching labs, with advanced features for upper-level coursework.
Manufacturing and Quality — Fast capture rate catches intermittent failures that slower scopes miss. Web remote control for rack-mounted setups.

Frequently Asked Questions

Can I add digital channels later?

Yes. The UT-M15 logic probe pod adds 16 digital channels. You also need the UPO2000-LA16 software license to enable the logic analyzer function.

Are serial bus protocol decodes included?

No. Protocol decoding for RS-232, UART, I²C, SPI, CAN, CAN-FD, LIN, and FlexRay is available as optional software licenses. See the MSO/UPO2000 series page for available decode options.

What is the difference between MSO and UPO models?

MSO models include the 16-channel logic probe pod. UPO models are the same oscilloscope without the logic pod — add it later with the UT-M15 and LA16 software license. All other specifications are identical.

What makes the 1,000,000 wfms/s capture rate significant?

A faster capture rate means the oscilloscope acquires more waveforms per second, increasing the probability of catching rare events like glitches, runts, or timing violations. At 1,000,000 wfms/s, the MSO/UPO2000 captures anomalies that scopes with 10,000–100,000 wfms/s would likely miss.

Part of the MSO/UPO2000 oscilloscope series. All models share the same 2.0 GSa/s sample rate, 56 Mpts memory, and 1,000,000 wfms/s capture engine. See the series comparison table to find the right combination of bandwidth, channels, and accessories.

Warranty

This instrument is backed by UNI-T's 3+2 Year Warranty — 3 years of standard coverage, plus 2 additional years free when you register your product. That's 5 years of total protection at no extra cost.

The warranty covers manufacturing defects and component failures under normal use conditions. UNI-T instruments are built for professional daily use, and our warranty reflects that commitment to long-term reliability.
