UTS3000-TG Tracking Generator Option
Overview
The UTS3000-TG adds a tracking generator — swept source synchronized with the analyzer for measuring insertion loss, return loss, and frequency response of filters, amplifiers, cables, and components.
Key Features
- Synchronized Sweep — Output tracks analyzer center frequency for stimulus-response measurements.
- Component Characterization — Measure insertion loss, passband flatness, and rejection directly.
- Cable Testing — Cable loss, antenna return loss, connector insertion loss across frequency.
- Normalization — Reference sweep calibration removes system losses.
- Software License Activation — License key via instrument menu. No hardware changes.
When You Need This
Filter Testing
Sweep a bandpass filter to verify center frequency, bandwidth, insertion loss, and rejection.
Cable Loss
Measure cable attenuation vs. frequency to select appropriate cables.
Compatible Instruments
This option is compatible with all UTS3000B/T Series spectrum analyzers.
Frequently Asked Questions
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
