UDP3303C 3Ch Classic-Series Programmable Linear DC Power Supply

Uni-T UDP3303C 3Ch Classic-Series Programmable Linear DC Power Supply Isometric Image

Uni-T UDP3303C 3Ch Classic-Series Programmable Linear DC Power Supply Back Image

A cost-effective program control DC supply with outstanding performance, reliable output, and clear interface.

DC Linear Type	3Ch Channels
195W Total Power	30V Output Voltage
3A Output Current	10mV/1mA Resolution

$319.00

Save {price}%

26 items in stock

Find a Distributor

Guarantee safe & secure checkout

The UDP3000 Series Programmable DC power supply is a cost-effective program control DC power supply with outstanding performance, reliable output and clear interface. The UDP3303C DC power supply has three independent outputs. Two of them are adjustable outputs of 30V/3A, the other one is a fixed selectable output of 1.8V/2.5V/3.3V/5V/3A (fine adjustable). With the constant voltage (CV) and constant current (CC) modes,short circuit and overvoltage protection features, the instrument can perfectly meet various test requirements.

	3 CH outputs，High precision Display 3 independent outputs, 4-digit voltage and current high-precision display: 10mV/1mA
Five sets of settings to save and recall Five groups of M1–M5 settings are saved and recalled, long press to store and short press to recall, making the test work efficient and convenient.
	Buzzer switch and key lock function, shutdown memory function, SET VIEW function Buzzer switch: switch the buzzer according to the working environment Key lock function: prevent accidental touch and wrong setting during normal working process Shutdown memory function: restore the last saved setting value next time the machine is turned on SET VIEW function: call preset value with one key
Remote control DIGITAL I/O interface The remote control power supply CH1/CH2 channels can be output and closed through DIGITAL I/O terminals

Feature	Specification
Model Number	UDP3303C
Channels	3Ch
Power Supply Type	DC Linear
Max V DC	30V
Max A DC	3A
Watts	195W
Max V Resolution	10mV
Max A Resolution	1mA
Programmable	true
Max A DC	3A
Max A Resolution	1mA
Touchscreen	No
Warranty	3 years
Product Dimensions (L x W x H)	9 in x 14 in x 7 in
Product Weight	19 lb
Certifications	CE/cTUVus
Documents	English download guide, multi-language safety manual, calibration report (COC)
Included Accessories	USB2.0 printing cable, alligator clip test cable (red + black)*2
Standard Accessories	Power cord
