UTE9806+ Smart Digital Power Meter | Ultra-Low Current Measurement Specialist

Overview

The UTE9806+ Smart Digital Power Meter represents a significant advancement in precision power measurement technology, specifically optimized for ultra-low current applications. With its exceptional ability to measure currents as low as 0.05mA, this instrument delivers unparalleled performance for standby power testing, energy efficiency validation, and sensitive electronic component analysis. The UTE9806+ features a sophisticated four-window display that simultaneously presents voltage, current, power, and power factor/frequency measurements, giving you comprehensive visibility into all critical power parameters.

Engineered with high-speed 32-bit MCU technology and premium low temperature drift resistors, the UTE9806+ ensures consistent measurement stability and accuracy even in challenging environments. Whether you're evaluating standby power consumption for regulatory compliance or conducting detailed power analysis for product development, this versatile instrument delivers the precision and functionality professional engineers and technicians demand.

Key Features

• Ultra-Low Current Sensitivity - Measures currents as low as 0.05mA with exceptional accuracy for standby power analysis
• Four-Window Display - Simultaneous visualization of voltage, current, apparent power, and power factor/frequency
• Switchable Parameter Windows - Customize which measurements appear in each display window for application-specific testing
• Advanced Alarm Functions - Configure upper and lower limits for voltage, current, power, apparent power, and power factor
• Automatic Range Selection - Optimizes measurement accuracy by automatically selecting the appropriate range
• Versatile Communication Options - RS-232 and RS-485 interfaces with SCPI and Modbus protocol support
• Comprehensive Measurement Parameters - Voltage, current, apparent power, power factor, and frequency
• Customizable Data Update Rate - Adjust from 0.1s to 5s based on testing requirements
• Average Function - Stabilizes readings for fluctuating loads and variable power sources
• Robust Construction - Fall-proof design with silicone angle protection for field and laboratory use
• PC Software Integration - Monitor, record, and analyze measurement data with included software package

UTE9806+ Details

Ultra-Low Current Measurement Excellence

The UTE9806+ excels in measuring extremely low currents down to 0.05mA, a capability that places it among the most sensitive power meters in its class. This exceptional sensitivity enables accurate analysis of standby power consumption, making it invaluable for compliance testing with energy efficiency regulations. Engineering teams can precisely evaluate circuit designs to minimize power consumption, while quality control departments can verify that finished products meet stringent energy efficiency standards.

Comprehensive Measurement Parameter Flexibility

Unlike conventional power meters with fixed display configurations, the UTE9806+ allows you to switch measurement parameters within each display window. This unique flexibility enables you to customize the instrument's interface to match your specific testing requirements. The ability to simultaneously monitor voltage, current, apparent power, and power factor provides a complete picture of device performance, reducing testing time and improving analysis efficiency.

Advanced Limit Testing and Alerting

The UTE9806+ offers expanded limit testing capabilities, allowing you to set upper and lower thresholds for voltage, current, active power, apparent power, and power factor. When measurements exceed these predefined limits, the instrument provides both audible and visual alerts, making it ideal for production testing and quality control applications. This comprehensive alerting system enables faster batch testing and immediate identification of out-of-specification units.

Superior Data Capture and Analysis

With adjustable data update periods ranging from 0.1 to 5 seconds, the UTE9806+ adapts to diverse testing scenarios from high-speed transient analysis to long-term power consumption monitoring. The average function further enhances measurement stability when working with loads that exhibit significant variations. These features, combined with comprehensive PC software integration, provide powerful tools for detailed power analysis and documentation.

Professional Applications

Energy Efficiency Compliance Testing

The UTE9806+ is the perfect instrument for evaluating device compliance with energy efficiency regulations like ErP, Energy Star, and similar international standards. Its ability to accurately measure ultra-low standby currents ensures reliable verification of power consumption limits. The instrument's comprehensive data logging capabilities also support the documentation requirements associated with regulatory certification.

Electronics Design and Development

For R&D engineers working on low-power electronics, the UTE9806+ provides critical insights into circuit performance and power consumption. Its high sensitivity allows detection of subtle changes in current draw, enabling optimization of power management systems and extending battery life in portable devices. The instrument's apparent power measurement capability is particularly valuable when analyzing reactive components and their impact on overall power efficiency.

Quality Control and Manufacturing Validation

Production facilities benefit from the UTE9806+'s comprehensive limit testing and alerting functions, which enable rapid pass/fail evaluation of manufactured units. The instrument's customizable display and measurement parameters can be configured to focus on the most critical specifications for each product line. Its robust construction withstands the demands of production environments while maintaining measurement precision.

Smart Home and IoT Device Testing

As connected devices proliferate in homes and businesses, power consumption has become a critical performance metric. The UTE9806+ allows manufacturers and developers to accurately measure the energy requirements of smart home systems, IoT sensors, and connected appliances. Its precision at low current ranges is essential for evaluating battery life projections and optimizing power management algorithms.

Technical Specifications

Optional Accessories

Package Contents

• UTE9806+ Smart Digital Power Meter
• Power cord
• Test leads
• User manual
• Calibration certificate
• RS232 serial port line (1)

UTE9800+ Series Comparison Table

Frequently Asked Questions

What makes the UTE9806+ ideal for standby power measurements?

The UTE9806+ can accurately measure currents as low as 0.05mA, which is essential for evaluating standby power consumption in modern electronic devices. This ultra-low current sensitivity, combined with high measurement accuracy, ensures reliable compliance testing for energy efficiency standards that regulate standby power limits.

How does the switchable parameter window function work?

The UTE9806+ uniquely allows you to assign different measurement parameters to each of its four display windows. Simply use the function keys to cycle through available parameters (voltage, current, apparent power, power factor, and frequency) for each window. This flexibility lets you customize the display to show exactly the measurements most relevant to your specific testing needs.

Can the UTE9806+ be used for both production testing and laboratory analysis?

Absolutely. The UTE9806+ includes features beneficial for both environments. Its comprehensive limit setting and alarm functions support efficient production testing, while its high precision and data logging capabilities satisfy detailed laboratory analysis requirements. The instrument's robust construction also ensures reliability in both settings.

What's the difference between apparent power and active power measurements?

Apparent power (VA) represents the total power in an AC circuit, including both real power consumed by the load and reactive power that oscillates between the source and load. Active power (W) measures only the real power consumed. The UTE9806+ measures both, providing a complete picture of device power consumption characteristics, particularly important for loads with reactive components.

How does the averaging function improve measurement stability?

When measuring devices with fluctuating power consumption, the averaging function applies a rolling average to stabilize the displayed readings. This makes it easier to interpret the overall power consumption patterns without being distracted by momentary variations. The function is particularly valuable when testing devices with cycling operational modes or variable loads.

Is the UTE9806+ suitable for testing multiple products simultaneously?

While each UTE9806+ unit measures a single device, multiple units can be networked via RS-485 interfaces for synchronized multi-device testing. The Modbus protocol support enables integration with supervisory control systems for managing multiple test stations. This capability is particularly valuable for production environments that require parallel testing of multiple units.

Customer Testimonials

"The UTE9806+'s ability to measure ultra-low currents has been crucial for our energy efficiency certification testing. We can accurately verify standby power consumption well below the most stringent international standards. The four-window display also gives us a complete picture of device performance at a glance." - Aisha M., Compliance Engineer

"We've implemented the UTE9806+ throughout our quality control process for IoT devices. The limit setting capabilities with visual and audible alarms have dramatically improved our testing efficiency. Failed units are identified immediately, and the data logging capabilities provide excellent documentation for our quality assurance records." - Thomas J., Production Manager

"As an electronics design engineer focused on low-power applications, the UTE9806+ has become my most valuable diagnostic tool. Its precision at extremely low current ranges allows me to identify power optimization opportunities that were previously undetectable with our older equipment." - Mei L., Senior Design Engineer

Warranty and Support

The UTE9806+ Smart Digital Power Meter comes with a comprehensive 3-year warranty covering manufacturing defects and component failures under normal use conditions. UNI-T provides dedicated technical support through our experienced team of application engineers. For technical assistance, contact our support hotline at 400-876-7822 or visit our support website.

Experience Unmatched Precision in Low-Current Measurement

Elevate your testing capabilities with the UTE9806+ Smart Digital Power Meter. With industry-leading sensitivity and comprehensive measurement capabilities, this instrument delivers the precision and versatility demanded by today's energy-conscious engineering and manufacturing environments. Order now to ensure your power measurement applications benefit from UNI-T's commitment to excellence and innovation.

[REQUEST A QUOTE] [BUY NOW] [DOWNLOAD DATASHEET]
