UTi32 High-Temp Thermal Imager

$189.00
Save {price}%

26 items in stock

Description

High temperature thermal camera specifically design for extreme applications

Top Specifications

32x32, -4°F-1832°F, 30°×30°, 9Hz, 2.4in LCD, Focus Free, Thermal Sensitivity (NETD): 150mK, Adjustable Emissivity
Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

OVERVIEW

SPECIFICATIONS

DOCUMENTATION

ACCESSORIES

UNI-T UTi32 Thermal Imager | Compact High-Temperature Diagnostic Tool

The UNI-T UTi32 Thermal Imager is a compact, powerful diagnostic solution designed for professionals who require precise temperature tracking across diverse industrial and maintenance applications. Offering an exceptional temperature detection range up to 1000°C, this thermal imager provides critical insights with remarkable ease of use and reliability.

Precision Temperature Monitoring in a Compact Design

Engineered to deliver professional-grade thermal imaging in a lightweight, user-friendly package, the UTi32 combines advanced technology with simplicity. Its focus-free operation, extensive temperature range, and multiple imaging modes make it an indispensable tool for technicians, engineers, and maintenance professionals.

Key Features

  • Compact 32x32 Pixel Infrared Resolution
  • Extensive Temperature Measurement Range: -20°C to 1000°C
  • 2.4" IPS Display with 480x320 Resolution
  • 300,000 Pixel Digital Camera Integration
  • Focus-Free Operation for Quick Deployment
  • Ultra-Long Battery Life (>7 Hours)
  • Multiple Image Modes: Thermal, Visual Image, Fusion
  • Advanced High/Low Temperature Tracking
  • Configurable Temperature Alarm System
  • Built-in LED Light
  • Flexible Emissivity Adjustment (0.01~1.00)
  • Type-C USB Charging

Advanced Thermal Imaging Technology

The UTi32 represents a breakthrough in compact thermal imaging technology. Its specialized 32x32 pixel infrared detector provides essential thermal visualization with remarkable capabilities. Despite its small size, the camera offers a comprehensive temperature tracking range from -20°C to 1000°C, making it versatile across numerous professional applications.

The focus-free design eliminates complex setup procedures, enabling immediate thermal assessments. Multiple imaging modes—including thermal, visual, and fusion views—provide professionals with comprehensive diagnostic perspectives. The high/low temperature tracking and configurable alarm system transform this compact device into a sophisticated monitoring tool.

Professional Applications

Industrial Temperature Monitoring

In industrial settings, the UTi32 excels at tracking temperature variations with exceptional precision. Its wide temperature range allows for comprehensive monitoring of equipment performance, helping technicians detect potential overheating issues and prevent catastrophic failures before they occur.

Electrical Systems Inspection

Electrical maintenance professionals can leverage the UTi32 to conduct rapid and non-invasive inspections of electrical systems. The camera's ability to detect temperatures up to 1000°C enables early identification of hotspots, loose connections, and potential electrical hazards that might compromise system integrity.

Mechanical Equipment Diagnostics

Mechanical engineers and maintenance technicians can use the UTi32 to perform predictive maintenance assessments. By visualizing temperature distributions in motors, bearings, and rotating equipment, professionals can identify wear, misalignment, and potential failure points before they lead to significant equipment damage.

HVAC and Building Performance Analysis

Building maintenance professionals can utilize the UTi32 to assess heating and cooling systems, detect insulation inefficiencies, and identify energy loss points. Its compact size and quick operation make it ideal for comprehensive building performance evaluations.

Research and Laboratory Applications

Researchers and laboratory technicians can employ the UTi32 for precise temperature monitoring in experimental setups. The camera's adjustable emissivity and wide temperature range make it suitable for various scientific and technical research applications.

Technical Specifications

Parameter Specification
Infrared Resolution 32 x 32 pixels
Display 2.4" IPS (480 × 320)
Temperature Measurement Range -20°C to 1000°C (-4°F to 1832°F)
Field of View 30°x30°
Digital Camera Resolution 300,000 pixels
Thermal Sensitivity (NETD) 0.15°C
Frame Rate <9Hz
Focus Focus Free
Accuracy ±2°C or ±2% whichever is greater
Emissivity Adjustment 0.01~1.00 (0.95 default)
Storage 16GB Micro SD card
Battery Fixed Li-ion battery (3.7V 5000mAh)
Battery Operation Time Over 7 hours
Image Modes Thermal, Visual Image, Fusion
Connectivity Type-C USB (Charging)
Certifications CE, UKCA, FCC, RoHS

Frequently Asked Questions

What distinguishes the UTi32 in the thermal imaging market?

The UTi32 stands out with its remarkable combination of compact design, extensive temperature range (up to 1000°C), ultra-long battery life, and professional-grade features. It offers an unparalleled balance of portability and functionality for professionals requiring reliable thermal diagnostics.

How accurate is the temperature measurement?

With an impressive accuracy of ±2°C or ±2% of the reading, the UTi32 provides highly precise temperature measurements. The adjustable emissivity feature further enhances measurement reliability across different material types and environmental conditions.

What are the primary advantages of the focus-free design?

The focus-free operation eliminates complex focusing procedures, enabling instant thermal assessments. This feature is particularly beneficial in fast-paced industrial environments where quick, reliable temperature tracking is crucial for maintaining operational efficiency and safety.

Can the UTi32 be used in challenging industrial environments?

Yes, the UTi32 is designed for robust performance. Its durable construction, wide temperature range, and certifications (CE, UKCA, FCC, RoHS) ensure reliable operation across diverse industrial and maintenance scenarios.

Professional Insights

"The UTi32 has revolutionized our predictive maintenance approach. Its ability to track temperatures up to 1000°C with such ease makes it an invaluable tool in our industrial inspection toolkit."

— Carlos Ramirez, Senior Maintenance Engineer

"As an HVAC specialist, I'm impressed by the UTi32's combination of simplicity and professional capabilities. The multiple image modes and focus-free design help me diagnose complex thermal issues quickly and efficiently."

— Sarah Thompson, HVAC Systems Specialist

What's in the Box

  • UTi32 Thermal Imager
  • Type-C USB Charging Cable
  • 16GB Micro SD Card
  • Protective Carrying Case
  • Quick Start Guide
  • Calibration Certificate

Warranty and Support

The UNI-T UTi32 comes with a comprehensive 1-year warranty covering manufacturing defects and component failures under normal use conditions. Backed by international certifications and UNI-T's commitment to quality, this thermal imager is supported by a dedicated technical support team ready to assist professionals in maximizing their diagnostic capabilities.

FeatureSpecification
Model Number UTi32
Resolution (px) 32px X 32px
FOV (Field of View) 30° x 30°
Max Temp (°F) 1832°F
Min Temp (°F) -4°F
Refresh 9Hz
NETD 150mK
Focus Focus Free
Warranty 1 year
Shipping Dimmensions (L x W x H) x x
Shipping Weight
